19" Enclosures
M6119235
COMBIMET T 19" 2Ux14.37" Open Top
Modern open top 19" rack case in aluminum with an anodized front panel and two ergonomic front panel handles. The ventilated one-piece case body has angled side panels and a short rear panel. The base is pre-punched for fitting PCB mounting pillars or the accessory internal mounting plate. All parts are provided with M4 earth studs for electrical continuity.
VersionOpen Top
Supply19" front panel, ventilated case body, 2 handle extrusions, M4 x 10 mm (x4), M3 x 8mm (x1). Supplied fully assembled.
Generate Your PDF Datasheet for M6119235
Please select the product details you would like to include in the PDF.
Accessory
M5600001
If PCB or mounting plate fixing screws are required please see our screw kit M5600010.
Supply 10 Nylon PCB pillars and 10 M3 x 6 mm fixing screws.
M5600001
PCB mounting kitBlack RAL 9005
M5900016
Supply M6 caged nuts (x4), M6 x 16 mm screw (x4) and black plastic cup washer (x4).
M5900016
19" mounting kit
M6000035
Supply M6 caged nuts (x4), M6 x 16 mm screw (x4) and light gray plastic cup washer (x4).
M6000035
19" mounting kit
M6200365
Supply Mounting plate, M3 nylon screw pillars (x9), M3 x 6 mm screws (x18).
M6200365
Mounting plate (14.37")Natural finish
13.19″x12.99″x0.06″
REACH compliant
IEC 60297-3
RoHS compliant
Catalog Pages
- COMBIMET 19" catalog (English) 4,068 KB
- Catálogo COMBIMET 19" (Español) 4,145 KB
Drawings
- PDF-File 254 KB
- AutoCAD DWG-File 513 KB
- AutoCAD DXF-File 3,052 KB
3D Models
- M6119235.sat 5,490 KB
- M6119235.stp 6,553 KB
- M6119235.x_t 4,319 KB
(METCASE product)
View our customizing options and don't forget to request a quotation!
